In the list on the left, expand the list item named “AB_ETHIP-1, Ethernet.”. To open RSLinx Classic Lite, hit the Windows key, type “rslinx,” and press the Enter key. Click “Close” to close the “Local Area Connection Properties” window. Click “OK” to close the “Internet Protocol Version 4 (TCP/IPv4) Properties” window. Ensure “Obtain an IP address automatically” is selected. In the “Local Area Connection Properties” window, select “Internet Protocol Version 4 (TCP/IPv4)” and click “Properties.”. The adapter’s icon will change as you do so.) Right-click on the Ethernet adapter you used in step 2 and select “Properties.” (If you’re not sure which adapter you’re using, just unplug the Ethernet cable and plug it back in. Open the “Network Connections” screen (Control Panel > Network and Sharing Center > Change adapter settings). Use an Ethernet cable to connect the Micro820 to you Windows machine. This means all you have to do is ensure you’re network adapter is also configured for DHCP and then open RSLinx. Using DHCPĪ new Micro820 will be configured for DHCP. These instructions assume you’re connecting to the Micro820 for the first time. The terminal blocks provide a way to connect switches and indicators, but they aren’t necessary: Connecting to the Micro820 for the first time Option 1: EthernetĮthernet is probably the simplest of the two methods, since you need only an Ethernet cable. When I decide on a layout I start wiring stuff: Putting the power supply on the left makes sense to me because I like to visualize the input to the power supply on the left and the output on the right, but whatever works for you. I start with a piece of 35 mm DIN rail (say 12-18 inches) and then I find an arrangement that makes sense. It works really well for the cubicle experimenter or electronics enthusiast, not so well for those in need of a legit control panel.īefore routing wires, it’s usually a good idea to put a little thought into the mechanical layout. Think of PLC on a stick as being analogous to a microcontroller experimenter board. The method presented here is what I call “PLC on a stick,” which is exactly the way it sounds, except it’s a rail and not a stick (but you can still use it to point at people). There are lots of ways to wire a PLC, and I have no idea which way is best for you. And you’ll have to restart your computer. Eventually you’ll make it to this screen: Unless you need one of the language packs (Chinese, Portuguese, French, Italian, German, or Spanish), I recommend installing the components/features which are selected by default. Run “setup.exe” as an administrator to install both RSLinx and CCW. It should contain a file named “setup.exe.” Open the subdirectory that was created in part 9. exe file (part 1) as an administrator to extract the.
Download both files (parts 1 and 2) to the same directory. Click “Accept” in the lower right-hand corner of the screen to accept the terms of the end-user license agreement.Once you’ve created an account, make sure you’re signed in and then repeat steps 1-3.Click “Sign up now” and follow the steps to create a Rockwell account.If you don’t have a Rockwell account, you’ll have to create one to download the software. This will open the “Website Member Sign In” page.Under “Standard” in the “Downloads” section, click “Version 1x.xx Software.” As of, the latest version of CCW is 10.01.To install CCW and RSLinx, follow these steps: RSLinx is installed automatically with CCW. If you’re just getting started, you’ll need to install both RSLinx and Connected Components Workbench (CCW). List of suggested materials Installing Connected Components Workbench Click on the link below to see what materials you might need. To start programming the Micro820, perform each of these tasks in the order they’re presented. Connecting to the Micro820 for the first time.Installing Connected Components Workbench.
This section describes how to perform three tasks:
Supports up to two Micro800 plug-in modules (complete list here). DeviceNet capability with a plug-in module. Has one Ethernet port (not common for this price range).
Without adding plug-in modules, you get 8 DIs, 7 DOs, 4 AIs, 1 AO, and 1 PWM output. At $250.00, it is considered a low cost (for Allen-Bradley) Ethernet controller. Can be programmed with ladder logic, structured text, and/or function blocks. The Micro820 is a low cost Ethernet controller in the Allen-Bradley Micro800 PLC family.
